MIL-DTL-10911/2B
PIN
Dimensions
M10911/2
1/
C
D
E
F
G
H
K
Y
Z
B
-01 & -02
6.12
2.75
3.38
.200
1.75
1.31
1.50
.375
6.94
6.25
±.003
1/ Dimension B = Mounting diameter.
Inches
mm
.003
.08
.200
5.08
.375
9.53
1.31
33.27
1.50
38.10
1.75
44.45
2.75
69.85
3.38
85.85
6.12
155.45
6.25
158.75
6.50
165.10
6.62
168.15
6.94
176.28
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only and are based upon 1 inch = 25.4 mm.
3. Unless otherwise specified, tolerances are ± .005 (.13 mm) for three place decimals, ± .02 (.51 mm) for two
place decimals, and ± 0° 30' on angles.
4. Configuration, other than mounting dimensions, is optional.
5. All Part or Identifying Numbers (PIN) shall be as specified in MIL-DTL-10911.
FIGURE 1. Loudspeaker Continued.
REQUIREMENTS:
Design and construction:
Dimensions and configuration: See figure 1.
Testing enclosure for measuring frequency response, harmonic distortion, and vibration: 14 x 14 x 7-inch test
cabinet.
Power capacity: 5 watts, rms.
Peak power capacity: 8 watts, rms.
Maximum weight: 2 lbs.
Voice coil impedance:
Dash number 01: 4-8 ohms.
Dash number 02: 45 ohms.
NOTE: Impedance variations may be accomplished by either the use of voice coils wound to meet the
specified impedance, or the installation of impedance matching transformers, providing other performance
characteristics are not adversely affected.
2
