INCH-POUND
MIL-DTL-24223/1B(SH)
28 January 2014
SUPERSEDING
A-A-59002/1
31 May 1995
MIL-L-24223/1A(SH)
22 October 1986
DETAIL SPECIFICATION SHEET
LOUDSPEAKER, SHIPBOARD ANNOUNCING SYSTEMS
ENCASED, 70 VOLT, 1 VOLT-AMPERES
Reinstated after (fill in date) and may be used for new and
existing designs and acquisitions.
This specification is approved for use within the Naval Sea Systems Command, Department of the Navy, and is
available for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and MIL-DTL-
24223.
B
C
2D
F (3 RQD)
D
1.25 O.D.
LAND (2 RQD)
3/32
C
A
E
L
+1/4
1/2 E -0
1.65 O.D.
LAND
C
L
SIDE ELEVATION
REAR VIEW
Maximum
Maximum dimensions (inches)
External volume
weight
control
A
B
C
D
E
F
(pounds)
1⅞
/32
65/8
17
LS-305()/SIC
10
11
8¼
4½
No
1⅞
65/8
/32
17
LS-306()/SIC
10
11
8¼
4½
Yes
1⅞
45/8
65/8
/32
17
LS-530()/SIC
10
11
8¼
No
1⅞
/32
45/8
65/8
17
LS-531()/SIC
10
11
8¼
Yes
FIGURE 1. Loudspeaker.
