MIL-PRF-26542/1E
Total harmonic distortion: Between 200 Hz to 6,000 Hz, 5 percent at 105 dB relative to 20
micropascals.
Resistive load: 150 ohms ±1.5 ohms.
Intended use: The microphone, including the boom and cord assembly, is intended for use in headset-
microphones requiring noise-canceling communications at both ground level and altitude.
PIN: Consists of the letter M, the basic number of the specification sheet, and a dash number compiled
from the code, as outlined in table I.
M26542/1-
0x
M prefix and specification sheet number
Dash number
The microphone assembly shall be tested in accordance with the tests listed in table II.
TABLE I. PIN designations.
*
PIN
Characteristics
M26542/1
Supplied with microphone element only.
M26542/1-01
Supplied with microphone element, boom,
and cable assembly specified.
5
