MIL-PRF-26542/8C
Frequency points (Hz)
300
600
1,300
2,400
3,000
4,000
6,000
Upper
limits (dB)
+4.0
+4.0
+4.0
+7.0
+7.0
+7.0
+1.0
Lower
limits(dB)
-16.0
-4.0
-4.0
-4.0
-4.0
-------
-------
FIGURE 4. Frequency response.
REQUIREMENTS:
Component parts:
Microphone element: Shall be in accordance with figure 1 or 2, as specified.
Cable assembly: Shall be in accordance with figure 3.
Cord assembly: One each electrical cord, PIN WD-27/U in accordance with MIL-DTL-10392 or PIN
WD-34/U in accordance with MIL-DTL-5898, for compatibility with performance requirements of this
specification sheet.
Plug assembly: JJ-055 type, PIN M641/8-1 in accordance with MIL-J-641/8, or an electrically and
mechanically equivalent part.
