INCH-POUND
MIL-PRF-87819/1B
30 September 2009
SUPERSEDING
MIL-PRF-87819/1A(USAF)
30 January 1997
PERFORMANCE SPECIFICATIONS SHEET
HEADSET-MICROPHONE, HEARING PROTECTIVE TYPE
HIGH AMBIENT NOISE LEVELS, 105-125 dB,
M87819/1-O1
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this
specification sheet and MIL-PRF-87819.
Letter
Inches
mm
Design dimension
Tolerances
Design dimension
Tolerances
A
1.50
+ 0.5 0.00
38.1
+ 12.7 0.0
B
28.5
± 2.0
732.9
± 50.8
C
12.0
± 0.5
304.8
± 12.7
FIGURE 1. Headset-microphone assembly M87819/1-01.
AMSC N/A
FSC 5965
