A-A-55568/1B
Electrical characteristics.
Receiver.
Output level. The receiver output level shall be 75.5± 4 dB SPL (12.6 mV rms through 600 ohms).
Distortion. Distortion for the headset shall be less than 5 percent.
Receiver impedance. The receiver impedance shall be 600 ohms nominal.
Microphone/amplifier.
Output level. The output level shall be -22.5 dB V ±4 dB V (47 to 119 mV rms).
(NOTE: All transmit measurements are made with 94 dB SPL drive at 1000 Hz into a 50 ohm resistive load at 100
mA dc. Also 0 dB m = 1 milliwatt; 0 dB SPL = .0002 dynes/cm2; 0 dB V = 1 volt.)
DC resistance. The dc resistance shall be greater than 35 ohms.
Terminal voltage. Terminal voltage shall be 4.7 V dc at 100 mA.
Microphone impedance. Microphone impedance shall be 50 ohms nominal.
Polarity. The microphone/amplifier shall be nonpolar.
Marking. Headsets supplied to this CID shall be marked with the manufacturer's (MFR's) standard commercial PIN.
TABLE I. Cable assembly characteristics.
AA55568/1-
Characteristics
01
The length of the coiled portion of the connector cable assembly
shall be 50.8 centimeters (20 inches) nominal when retracted
and 3.05 meters (10 feet) nominal when extended.
02
The length of the coiled portion of the connector cable assembly
shall be 76.2 centimeters (30 inches) nominal when retracted
and 4.57 meters (15 feet) nominal when extended.
03
The length of the coiled portion of the connector cable assembly
shall be 127 centimeters (50 inches) nominal when retracted
and 7.62 meters (25 feet) nominal when extended.
