A-A-55568/2C
TABLE I. Cable assembly characteristics.
PIN
Characteristics
AA55568/02
Headset-microphone with non-noise-canceling voice tube
001
design. The length of the coiled portion of the connector cable
assembly shall be 50.8 centimeters (20 inches) nominal when
retracted and 3.05 meters (10 feet) nominal when extended.
(reference Fig. 1)
Headset-microphone with non-noise-canceling voice tube
002
design. The length of the coiled portion of the connector cable
assembly shall be 76.2 centimeters (30 inches) nominal when
retracted and 4.57 meters (15 feet) nominal when extended.
(reference Fig. 1)
Headset-microphone with non-noise-canceling voice tube
003
design. The length of the coiled portion of the connector cable
assembly shall be 127 centimeters (50 inches) nominal when
retracted and 7.62 meters (25 feet) nominal when extended.
(reference. Fig. 1)
Headset-microphone with noise-canceling unidirectional
microphone design. The length of the coiled portion of the
connector cable assembly shall be 50.8 centimeters (20 inches)
004
nominal when retracted and 3.05 meters (10 feet) nominal
when extended. (reference Fig. 1)
Headset-microphone with noise-canceling unidirectional
microphone design. The length of the coiled portion of the
005
connector cable assembly shall be 76.2 centimeters (30 inches)
nominal when retracted and 4.57 meters (15 feet) nominal
when extended. (reference Fig. 1)
Headset-microphone with noise-canceling unidirectional
microphone design. The length of the coiled portion of the
006
connector cable assembly shall be 127 centimeters (50 inches)
nominal when retracted and 7.62 meters (25 feet) nominal
when extended. (reference Fig. 1)
5
