INCH-POUND
MIL-DTL-24223/2B(SH)
28 January 2014
SUPERSEDING
MIL-L-24223/2A(SH)
22 October 1986
DETAIL SPECIFICATION SHEET
LOUDSPEAKER, SHIPBOARD ANNOUNCING SYSTEMS
ENCASED, 70 VOLT, 6 TO 15 VOLT-AMPERES
Reinstated after 28 January 2014 and may be used for
new and existing designs and acquisitions.
This specification is approved for use within the Naval Sea Systems Command, Department of the Navy, and
is available for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-24223.
C
2D
F (3 RQD)
1.25 O.D.
LAND (2 RQD)
D
C
3/32
B
E
L
G
1.65 O.D.
LAND
CABLE
ENTRANCE
A
REAR VIEW
SIDE ELEVATION
OF BASE
CONFIGURATION IS OPTIONAL
Maximum Dimensions (inches)
Nomenclature
Maximum Weight
A
B
C
D
E
F
G
(pounds)
5⅛
125/8
125/8
215/16
/16
7
LS 387()/SIC
25
10
25/8
*LS 388()/SIC
1⅞
/16
65/8
7
LS 535()/SIC
10
8¼
10¼
5½
N/A
*LS 536()/SIC
*External volume control
FIGURE 1. Loudspeaker.
AMSC N/A
FSC 5965
