INCH-POUND
MIL-DTL-24223D(SH)
28 January 2014
SUPERSEDING
MIL-L-24223C(SH)
22 October 1986
DETAIL SPECIFICATION
LOUDSPEAKER, PERMANENT MAGNET, SHIPBOARD ANNOUNCING SYSTEMS
Reinstated after 28 January 2014 and may be used for
new and existing designs and acquisitions.
This specification is approved for use by the Naval Sea Systems Command Department of the Navy, and is
available for use by all Departments and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers permanent magnet loudspeakers, with enclosure, for use in 70-volt and
95-volt distribution systems on Naval ships as components of shipboard announcing systems.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3, 4, or 5 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATIONS
MIL-PRF-27
-
Transformers and Inductors (Audio, Power, and High-Power Pulse),
General Specification for
MIL-S-901
-
Shock Tests, H.I. (High-Impact) Shipboard Machinery, Equipment, and
Systems, Requirements for
MIL-DTL-1222
-
Studs, Bolts, Screws and Nuts for Applications where a High Degree of
Reliability is Required; General Specification for
MIL-DTL-15024
-
Plates, Tags, and Bands for Identification of Equipment, General
Specification for
MIL-P-15024/5
-
Plates, Identification
MIL-DTL-24223/1
-
Loudspeaker, Shipboard Announcing Systems Encased, 70 Volt, 1 Volt-
Amperes
Comments, suggestions, or questions on this document should be addressed to: Commander, Naval Sea Systems
Command, ATTN: SEA 05S, 1333 Isaac Hull Avenue, SE, Stop 5160, Washington Navy Yard DC 20376-5160 or
emailed to CommandStandards@navy.mil, with the subject line "Document Comment". Since contact information
can change, you may want to verify the currency of this address information using the ASSIST Online database at
https://assist.dla.mil.
AMSC N/A
FSC 5965
