MIL-DTL-9415B
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.0156
0.39624
.343
8.7122
.938
23.8252
1.938
49.2252
.03125
0.79375
.375
9.525
1.00
25.4
2.00
50.8
.0625
1.5875
.438
11.1252
1.125
28.575
2.563
65.1002
.063
1.6002
.531
13.4874
1.156
29.3624
2.875
73.025
.083
2.1082
.563
14.3002
1.313
33.3502
3.219
81.7626
.125
3.175
.594
15.0876
1.438
36.5252
3.469
88.1126
.141
3.5814
.688
17.4752
1.50
38.1
3.6875
93.6625
.1875
4.7625
.75
19.05
1.563
39.7002
3.844
97.6376
.25
6.35
.844
21.4376
1.625
41.275
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified tolerances are. .XX ± .02 (.5mm), .XXX ± .005 (.13mm), angles ± 2º
FIGURE 5. Audio frequency amplifier AM-492B/AIC-10 Continued.
3.11 Color and finishes. The exterior normally-exposed surface of Dynamic Loudspeaker LS-184A/AIC-10 shall
be a lusterless black finish, color no. 37030, 37031 or 37038 (color number at the option of the manufacturer) in
accordance with FED-STD-595.
3.12 Identification of product. Dynamic Loudspeaker LS-184A/AIC-10 shall be marked for identification in
accordance with MIL-STD-130. The marking shall include the following information (see figure 1).
