MIL-DTL-9415B
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in the contract or order
(see 6.2). When packaging of materiel is to be performed by DoD or in-house contractor personnel, these personnel
need to contact the responsible packaging activity to ascertain packaging requirements. Packaging requirements are
maintained by the Inventory Control Point's packaging activities within the Military Service or Defense Agency, or
within the military service's system commands. Packaging data retrieval is available from the managing Military
Department's or Defense Agency's automated packaging files, CD-ROM products, or by contacting the responsible
packaging activity.
6. NOTES
(This section contains information of a general or explanatory nature, which may be helpful but is not mandatory.)
6.1 Intended use. Dynamic Loudspeaker LS-184A/AIC-10 is intended to be used as part of Intercommunications
Set AN/AIC-10a at low altitudes to permit stand-by listening on long missions in military aircraft.
6.2 Acquisition requirements. Acquisition documents should specify the following:
a. Title, number, and date of this specification.
b. If first article is required (see 4.3).
c. Levels of preservation and packing required (see 5.1).
d. If special or additional identification marking is required (see 5.1).
6.2.1 Ordering data. Invitations for bids, contracts and purchase orders should state the conditions for the
following.
6.2.2 First article tests. It is expected that the contract or purchase order will specify that a minimum of ten each
Dynamic Loudspeaker LS-184A/AIC-10 will be required, as first article samples to be subjected to the first article
tests by the contractor. To determine compliance with the requirements of this specification, five each Dynamic
Loudspeaker LS-184A/AIC-10 will be required as first article samples to be submitted to the procuring activity.
6.3 Tin whisker growth. The use of alloys with tin content greater than 97 percent, by mass, may exhibit tin
whisker growth problems after manufacture. Tin whiskers may occur anytime from a day to years after manufacture
and can develop under typical operating conditions, on products that use such materials. Conformal coatings applied
over top of a whisker-prone surface will not prevent the formation of tin whiskers. Alloys of 3 percent lead, by mass,
have shown to inhibit the growth of tin whiskers. For additional information on this matter, refer to ASTM-B545
(Standard Specification for Electrodeposited Coatings of Tin) (see 3.2.2).
6.4 Environmentally preferable material. Environmentally preferable materials should be used to the maximum
extent possible to meet the requirements of this specification. Table XI lists the Environmental Protection Agency
(EPA) top seventeen hazardous materials targeted for major usage reduction. Use of these materials should be
minimized or eliminated unless needed to meet the requirements specified herein (see Section 3).
TABLE XI. EPA top seventeen hazardous materials.
Benzene
Dichloromethane
Tetrachloroethylene
Cadmium and Compounds
Lead and Compounds
Toluene
Carbon Tetrachloride
Mercury and Compounds
1,1,1 - Trichoroethane
Chloroform
Methyl Ethyl Ketone
Trichloroethylene
Chromium and Compounds
Methyl Isobutyl Ketone
Xylenes
Cyanide and Compounds
Nickel and Compounds
24
